Main Applications
● Installation and setup.
● Repair and maintenance.
● Shipbuilding and offshore.
● Chemical and process industry.
● Piping and pressure vessel tank
Advantageous
● TIG AC/DC digital control .
● Program memory storage up to 50 sets of data.
● Microprocessor control of a wide range of functions.
● Multi wave options on AC.
● Remote control interface.
● VRD function.
● Intelligent fan and cooler control.
● Excellent welding characteristics.
| Specifications | |
| TIG load capacity at 40°C | |
| Tig Welding range | 10 A / 10.4V … 315 A / 22.6 V |
| At 30 % duty cycle | 315 A |
| Rated power at max. current | 14 KVA |
| MMA load capacity at 40°C | |
| MMA welding range | 10 A / 20.4 V … 270 A / 30.8 V |
| At 30 % duty cycle | 270 A |
| Rated power at max. current | 15 KVA |
| Electrode range | Ø 1.5 … 6.0 mm |
| Open circuit voltage, max. | 73 V DC |
| Welding current adjustment | Stepless |
| Input phase | 3 Phase |
| Main voltage, Tolerance | 400 V, -15 % … +20 % |
| Connection cable / fuse | 4 x 2.5 mm2 / 16 A |
| Efficiency at max. current | 80 |
| Power factor | 0.7 |
| Index protection | IP 21 S/F |
| Dimensions ( L x W x H ) | 566 x 224 x 405 mm |
| Weight | 25.5 Kg |
