Penggunaan Utama
● Instalasi dan outfitting
● Perbaikan dan pemeliharaan
● Industri kimia dan pengolahan
● Mekanis dan elektrikal
● Pengelasan pipa
● Pabrikasi baja
● Industri berat
● Industri Minyak & gas
Keunggulan
• TIG DC with HF and 2T & 4T functions & Pulse Mode
• Constructed to be used on work sites and extreme conditions
• Selector switch for Tig or MMA Welding
• Digital display for accuracy setting
• Adjustable down slope 0 ~ 10 s and post flow time 0 ~ 5 s
• Useable at generator supply
• Adjustable Pulse Frequency 1 – 10 Hz
• Exceptional ignition and excellent arc welding characteristics
• Pulse Current 0 – 100 %
• Lightweight and portable
| Item Code | Item name |
| 101.07.007.1 | T 360 P - TIG DC Air Cooled package |
| 101.07.007.2 | T 360 P - TIG DC Water Cooled Package |
| • Control Plug 5 pin - 1 pc | |
| • Gas Out Connector - 1 pc | |
| • Gas Hose at 2 m - 1 pc |
| TIG | T 360 P |
| Tungsten range | 1.6 - 4.0 mm |
| Material thickness | 1 - 10 mm |
| MMA | |
| Electrode range | 1.6 - 8.0 mm |
| Material thickness | 1 - 16 mm |
| Spesifikasi | |
| Welding range | TIG 10 - 360 A |
| MMA 10 - 320 A | |
| Load voltage | TIG 10.4 - 24.4 V |
| MMA 20.4 - 32.8 V | |
| Open circuit voltage | 69 V |
| Current at 60 % ( 40°C ) | 360 A |
| Current at 100 % ( 40°C ) | 279 A |
| Input power at max. current | 11.2 KVA |
| Input current at 60 % | 16.9 A |
| Input phase | 3 Phase |
| Main voltage | 380 V |
| Frequency | 50 / 60 Hz |
| Efficiency | 0.85 |
| Power factor | 0.93 |
| Index protection | IP 23 |
| Insulation class | F |
| Cooling | F |
| Dimensions ( L x W x H ) | 490 x 220 x 395 mm |
| Weight | 24 Kg |
